Samsung MZ-M5E250BW 120GB 6Gb/s SATA Triple-Level Cell 1.8-inch SSD

* NOTE: Image may not exactly match the product

Samsung MZ-M5E250BW 120GB 6Gb/s SATA Triple-Level Cell 1.8-inch SSD

Part Number:

MZ-M5E250BW

Manufacturer:

Samsung

Availability:In Stock
Warranty: 1 Year (Return/Replacement)

Request a quote

Or call (800) 733-1169
Shipping Options:
  • Ships Same Business Day ( If ordered before 2:00pm EST)
  • Free Ground Shipping ( Contiguous US and Canada)
  • Expedite Shipping in US
30 Days Return Warranty
Accept Payment
  • Visa
  • Discover
  • Mastercard
  • Pay with wire transfer
  • AMEX
Process POs for Government Agencies, Enterprises, Data Centers and SMBs

Need Assistance? We are here to help!

  • Call us at (800) 733-1169
    Monday to Friday, 8:00 am - 5:00 pm PST
  • Email: [email protected]
  • Live Chat with Technical Sales

Product Description

Samsung MZ-M5E250BW 850 EVO Series 120GB Triple-Level Cell SATA 6Gb/s mSATA 1.8-Inch Solid State Drive

Key takeaways

  • Samsung MZ-M5E250BW is a 120GB 6Gb/s SAS internal solid state drive for server use, with Triple-Level Cell flash and 850 EVO series.
  • Sold refurbished and a package quantity of 1.
  • Reference part number MZ-M5E250BW when matching this listing to a quote, purchase order or existing inventory; Memory Clearance lists it under Solid State Drives.
  • Quoted on request; no list price is published for this part number. Include the quantity needed with the quote request.

The Samsung 850 EVO MZ-M5E250BW SSD delivers exceptional performance with 120GB of storage for client PCs. It boasts impressive read/write speeds of up to 540/520 MB/s and random read/write IOPS reaching 97k/88k. Its sleek 1.8-inch design and SATA 6Gb/s interface ensure compatibility with 3Gb/s and 1.5Gb/s systems. Leveraging advanced V-NAND technology, it outperforms traditional NAND by stacking memory cells vertically.

Key specifications

The figures below come from this listing's own record. They are the ones that decide whether a part drops into an existing system.

  • Storage Capacity: 250 GB. Usable capacity as the manufacturer states it.
  • Drive Interface: SAS. The bus the drive expects; the controller or backplane has to present the same one.
  • Interface Standard: 6Gb/s SAS. The negotiated link standard.
  • Drive Type: Internal. Where the drive is designed to sit.
  • Drive Width: 1.8". Bay width, which decides whether it drops into the slot.
  • Flash Memory Technology: Triple-Level Cell. The NAND type, which tracks with endurance and cost.
  • Form Factor: mSATA. The size or mounting class the catalogue records for this part.
  • Compliance Standards: RoHS. The standards and certifications recorded for this part.

Confirming fit

Memory Clearance does not publish a verified compatibility list for MZ-M5E250BW. Whether a part of this type is supported is defined by the system or switch vendor's own compatibility matrix, not by the part on its own.

The dependable check is the part number. Read the installed part number from the system's management interface and compare it with the number on this listing. If you send your server model with a quote request, it is checked against this part before you order.

Other Samsung Solid State Drives listings

Other parts in the same brand and category. These are not substitutes for this part number; check the specification before ordering.

Common questions

Is MZ-M5E250BW in stock?

Stock moves, so the quantity shown on this listing is the current figure. For a larger quantity, send the part number and how many you need and the answer comes back against that exact number. Quotes are answered weekdays 8:00 am to 5:00 pm PST.

Does this drive come with a tray?

Only if the listing name says so. Drive listings are either bare or supplied in a generation-matched hot-swap tray, and the name states which.

Can I use this to replace a failed array member?

Match the interface, the capacity, the sector format and the class of the drive already in the array. A mismatch on any of those can be rejected by the controller.

What do I send to get a price on MZ-M5E250BW?

The part number, the quantity, the condition you will accept and the server model it goes into. That is enough to answer in one pass.

Guides

Browse related listings

•Samsung Magician Software for SSD Management

•Equipped with V-NAND, MEX/MGX controllers, DRAM, and software integration

•Enhanced data security featuring AES 256-bit encryption, TCG/Opal V2.0, and IEEE1667 standards

•Power-efficient with a peak consumption of 2.7W and 50mW during idle

•Securely erase or initialize data using the crypto erase service with PSID

General Information

Product Series
850 EVO
Product Type
Solid State Drive

Technical Information

Drive Type
Internal
Drive Width
1.8"
Flash Memory Technology
Triple-Level Cell
Storage Capacity
250 GB

Interfaces/Ports

Drive Interface
SAS
Interface Standard
6Gb/s SAS

Physical Characteristics

Form Factor
  • mSATA

Miscellaneous

Compliance Standards
  • RoHS
